OSHIMA K5 - Page 73

K5-190 零件表 Parts List 3D-12
NO.
零件号
名称
Compellation
NO.
零件号
名称
Compellation
1
KS3B228
固摺器滑座墊圈
Sleeve
16
06.10.03.3001
海棉條
Sponge
2
KS3B231
固摺器滑座上壓板
Hold Plate
17
KS3A088
針布槽
Needle Plate Chase
3
KS3B229
固摺器滑座底板
Stand of Slider
18
KS3B232
固摺器 ARM 軸
Shaft
4
BZ039
固摺器壁 A
Frame A - Fixed Catcher
19
BZ009
持平六角棒
Horizontal Pole of F-Catcher
5
KS3B215
水平培林軸
Shaft
20
KS3B233
固摺器幹管
Joint Pipe of F-Catcher
6
KS3B216-L
固摺器持平板 A
Horizontal Plate A
21
KS3B262
插梢
Fix Pin
7
KS3B217
持平六角棒軸心
Shaft
22
KS3A100
固摺器壁定位角鐵
Stand of Slider
8
KS3B220
持平板襯套
Sleeve
23
KS3B216-R
固摺器持平板 B
Horizontal Plate B
9
KS3B221
升降滑道培林軸
Shaft
24
KS3B235
固摺器升降臂夾頭 B
Lifting Arm Holder B
10
KS3B223
固摺器升降臂夾頭 A
Lifting Arm Holder A
25
KS3B218
固摺器壁 B
Frame B - Fixed Catcher
11
BZ036
固升降臂 A
Lifting Arm A
26
KS3B236
固升降臂 B
Lifting Arm B
12
BZ044
81512 培林軸
Shaft
27
04.07.01.2121
培林 6002ZZ
Bearing
13
AZ044
固摺器針板臂
Chase Frame of F-Catcher
28
04.07.01.4001
培林 NK0812
Bearing
14
KS3B237
針板殼端塞
Stopple of Chase
29
04.07.01.4004
培林 NK1012
Bearing
15
06.10.03.4201
針板
Needle Plate
30
04.07.01.3002
乾式軸承 DU0808
Bearing
