OSHIMA K5 - Page 74

K5-190 零件表 Parts List 3D-13
NO.
零件号
名称
Compellation
NO.
零件号
名称
Compellation
1
AZ001
移摺器鎖固滑板座 1
Stand of Slide Plate 1
31
KS3B221
升降滑道培林軸
Shaft
2
AZ002
移摺器鎖固滑板 B 前
Slide Plate B-F
32
BZ013
三角板軸心
Shaft
3
KS3B241
移摺器鎖固軸滑塊 B
Slide Block B
33
BZ015
水平培林軸
Shaft
4
AZ003
移摺器鎖固滑板 B 後
Slide Plate B-R
34
BZ011-190
移摺器幹管
Joint Pipe of M-Catcher
5
AZ004
移摺器鎖固滑板座 2
Stand of Slide Plate 2
35
AZ022
持平三角板 A
Horizontal Plate A
6
AZ056
K9 弧軌 b
Guide Plate b
36
BZ014
持平六角棒軸心後
Shaft
7
AZ050
移摺器升降板 B
Lifting Plate B of M-Catcher
37
AZ055
K9 弧軌 a
Guide Plate a
8
BZ001
移摺器升降臂夾頭 B
Lifting Arm Holder B
38
AZ035
墊板
Bolster
9
AZ008
移摺器壁 B
Frame B of Moving Catcher
39
AZ054
上位勾
Hook
10
AZ051
針板壁 B
Chase Frame B of M-Catcher
40
BZ047
上位勾軸
Shaft
11
BZ043
滑軌 B
Slider B
41
AZ027
橫軌墊板 2
Guide bolster 2
12
KS3A088
針布槽-190
Needle Plate Chase
42
AZ028
橫軌墊板 1
Guide bolster 1
13
06.10.03.3001
海棉條
Foam Rubber
43
AZ029
移摺器壁 A
Frame A of Moving Catcher
14
06.10.03.4201
針板
Needle Plate
44
AZ033
移摺器吊簧上勾板
Upper Hook Plate
15
KS3B237
針板殼端塞
Stopple of Chase
45
KS3B311
移摺器拉簧
Spring
16
AZ053
針板壁 A
Chase Frame A of M-Catcher
46
KS3A092
移摺器吊簧勾板
Lower Hook Plate
17
BZ044
81512 培林軸
Shaft
47
BZ021
滑板座固定柱
Pole
18
BZ045-190
連結扁管-190
Joint Rectangle Pipe
48
BZ022
走行 6002 軸心
Shaft
19
KS3A097
伸縮拉簧板
Spring Hook
49
AZ030
邊導輪座板
Stand of Bearing
20
KS3B317
伸縮拉簧
Spring
50
BZ023
邊導輪軸心 a
Shaft
21
KS3A089
止伸縮螺帽片
Nut Plate
51
KS3B275
滑板座墊圈
Sleeve
22
KS3B279
608 軸絲
Shaft
52
BZ024
邊導輪軸心 b
Shaft
23
KS3B278
608 軸絲
Shaft
53
AZ031
移摺器鎖固滑板 A 前
Slide Plate A-F
24
AZ052
移摺器升降板 A
Lifting Plate A of M-Catcher
54
KS3B254
鎖固夾頭
Vice
25
BZ046
滑軌 A
Slider A
55
AZ032
移摺器鎖固滑板 A 後
Slide Plate A-F
26
BZ008-190
移摺器 ARM 軸-190
Shaft
56
BZ025
鎖固軸墊圈
Sleeve
27
BZ009
持平六角棒
Horizontal Pole of M-Catcher
57
KS3B299
滑塊圈套
Sleeve
28
BZ007
持平六角棒軸心前
Shaft
58
KS3B258
移摺器鎖固軸滑塊
Slide Block A
29
BZ010
移摺器升降臂夾頭 A
Lifting Arm Holder A
59
BZ026-190
鎖固軸-190
Shaft
30
BZ012
升降臂
Lifting Arm
60
BZ027
紙支柱 6002 軸心
Shaft
