SPECIFICATIONS)
Model
OB-700/EA OB-700A/I OB-900/EA OB-900A/I OB-1200/EA OB-1200A/I
Power
3P/380V 1P/220V 3P/380V 1P/220V 3P/380V 1P/220V
Table Size
1200*1500mm 1500*1800 mm 1500*2400 mm
Cutting Capacity
180mm 180mm 280mm
Arm Length
700mm 900mm 1200mm
Knife Size
0.45*10* 3500 mm 0.45*10*3860mm 0.45*10*4560 mm
Net Weight
265kg 285kg 320kg
Packing volume
1500*700*1700mm 1600*700*1700mm 1920*800*1800mm
2
．
OPERATING METHOD
1.1 Connect to correct voltage.
1.2 Machine must do the horizontal adjustment and equip knife with right angle against to
surface of table.
1.3 Press down “ON” of “KNIFE”, and then knife will work automatically. Press down
“ON” of air, and then the wind will blow out from table.
1.4 There are two sets of oil tanks inside machine. Please inject silicon oil when oil runs out.
1.5 Knife should be grinded once it can’t cut fabric smoothly. Machine attaches grinder, so
knife will be edgy after grinding just need to push the holder of grinder.
1.6 All bearings must be injected “oil” every half a year to reduce the noise and increase
bearings’ lives.
1.7 There are blowing holes on the table. Please always keep them clear to avoid stemming
and influencing the power of blower.
1.8 Please adjust the knife applicably when replace a new knife. Don’t adjust the knife too
loose or too tight.
3
．
CAUTION
a) Please wipe the oil on the knife when you install the knife. The oil on the knife is for
rustproof purpose.
b) Please take the tape off. The parts No for the tape on the driving pulley is NO.700A006
4
．
NOTES FOR USAGE & MAINTENANCE
a) Please operate the touch panel gently.
b) Please keep the oil tank clean and fuel all the time.
c) When the band is not sharpened, please use the grinding device to sharpen the band.
d) When grinding stone is worn out, please adjust the lever to keep the two pieces of
To Next Page
