osily OSEF - Page 26

26
EN
S
L
N
LT(1)
L(2)
N(3)
L
N
LT(1)
L(2)
N(3)
S
Humidity
exceeds set point
Activation of turn-off
delay timer (2-30 minutes)
Activation of turn-on
delay timer (0-2 minutes)
S switch is OFF
during countdown of turn-on
delay timer
No
No
Yes
Yes
S switch to ON
or pull cord switch
Yes
Humidity
exceeds set point
No
Fan runs at speed 1
Fan runs at speed 1
Fan runs at speed 1
Fan does not run
Fan runs at speed 2
Fan runs at speed 1
Fan runs at speed 1
Fan runs at speed 2
S switch to OFF
or pull cord switch
Fan runs at speed 1
No
S switch to ON
or pull cord switch
Yes
... 150 Z1H
Humidity is below set point Humidity is below set point
Humidity is below set point
20.
ON
1
2
3
4
Operation
mode 5
