osily OSEF - Page 27

27
EN
ON
1
2
3
4
ON
1
2
3
4
ON
1
2
3
4
L
N
LT(1)
L(2)
N(3)
... 150 Z1PIR
Operation mode 1 Operation mode 2 Operation mode 3
Fan does not run
Motion detected
Activation of turn-off
delay timer (0-2 minutes)
No more motion detected
during countdown of turn-on
delay timer
No
Yes
Fan runs at speed 1 Fan runs at speed 2 Fan runs at speed 2
Fan runs at speed 1
No motion detected
Activation of turn-off
delay timer (2-30 minutes)
Activation of turn-off
delay timer (2-30 minutes)
Activation of turn-off
delay timer (2-30 minutes)
Fan does not run
Motion detected
Activation of turn-off
delay timer (0-2 minutes)
No more motion detected
during countdown of turn-on
delay timer
No motion detected
Motion detected
Activation of turn-off
delay timer (0-2 minutes)
No more motion detected
during countdown of turn-on
delay timer
Yes
No
No motion detected
No
Yes
21.
