Oster OTF9115R - Page 7

1. Assemble Base Halves around the cord.
Refer to FIGURES 2 & 3.
2. Secure assembled base to the Fan Housing with
4 Philips head screws as shown in FIGURE 2.
3. Secure Power Cord as shown in FIGURE 3.
ASSEMBLY INSTRUCTIONS
Fig. 1
Fig. 5
Fig. 2
Fig. 3
A
B
C
D
E
F
Fig. 6
Fig. 4
