OTC 6489 - Page 3

Parts List & Operating Instructions
Ford Tool Application Chart
Year Model Engine Tool Description Part No.
Ford
American
Part No.
Ford
Global Part
No.
1997-2011 Explorer 4.0L SOHC V6 VIN E Cam Gear Holding Tool
Crankshaft Holding Tool
Cam Holding Tool Adapter
Cam Holding Tool
Cam Gear Holding Tool Adapter
Timing Chain Tensioner Tool
Cam Gear Bolt Socket & Extension
6478 (511546)
6479 (511547)
6480 (511548)
6481 (511549)
6482 (511550)
6484 (511552)
6485 (511553 & 4)
T97T-6256-B
T97T-6303-A
T97T-6256-D
T97T-6256-C
T97T-6256-A
T97T-6K254-A
T97T-6256-F, -G
303-564
303-573
303-576
303-577
303-578
303-571
303-565, -575
1999-2002 Explorer 4.0L Push Rod V6 Cam Sensor Synch Tool 6483 (511551) 303-638
1997-2002 Explorer 4.6L VIN W Cam Positioning Tool
Cam Positioning Tool
6009 (511532)
6020 (511555)
T91P-6256-A
T92P-6256-A
303-380
303-413
1996-1998 Explorer 5.0L V8 Cam Sensor Synch Tool 6469 (511536) T96T-12200-A 303-562
1999-2002 Explorer 5.0L V8 Cam Sensor Synch Tool 6470 (511537) 303-630
1997-2004 F-150 4.6L VIN 6 Cam Positioning Tool
Cam Positioning Tool
6009 (511532)
6020 (511555)
T91P-6256-A
T92P-6256-A
303-380
303-413
1997-2010 F-150 4.6L VIN W Cam Positioning Tool
Cam Positioning Tool
6009 (511532)
6020 (511555)
T91P-6256-A
T92P-6256-A
303-380
303-413
1997-2008 F-Series Truck 4.2L Cam Sensor Synch Tool 6469 (511536) T96T-12200-A 303-562
1997-1998 F-Series Truck 4.6L Cam Positioning Tool
Cam Positioning Tool
6009 (511532)
6020 (511555)
T91P-6256-A
T92P-6256-A
303-380
303-413
1997-2002 F-Series Truck 4.6L Cam Positioning Tool 6476 (511543 & 4) T96T-6256-AR 303-S568
1997-2009 F-Series Truck 4.6L VIN W Cam Holding Tool 6477 (511545) T96T-6256-B 303-557
1997-2002 F-Series Truck 5.4L Cam Positioning Tool
Cam Positioning Tool
Cam Positioning Tool
6009 (511532)
6476 (511543 & 4)
6020 (511555)
T91P-6256-A
T96T-6256-AR
T92P-6256-A
303-380
303-S568
303-413
1997-2002 F-Series Truck 5.4L Cam Holding Tool 6477 (511545) T96T-6356-B 303-557
2012-2014 Focus 2.0L VIN 2 Cam Alignment Tool
Crankshaft TDC Timing Pin
6474 (511541)
6475 (511542)
T94P-6256-CH
T97P-6000-A
303-465
303-574
2000-2004 Focus 2.0L VIN 3 Cam Alignment Tool
Crankshaft TDC Timing Pin
6474 (511541)
6475 (511542)
T94P-6256-CH
T97P-6000-A
303-465
303-574
2002-2004 Focus 2.0L VIN 5 Cam Alignment Tool
Crankshaft TDC Timing Pin
6474 (511541)
6475 (511542)
T94P-6256-CH
T97P-6000-A
303-465
303-574
2005-2011 Focus 2.0L VIN N Crankshaft TDC Timing Pin 6475 (511542) T97P-6000-A 303-574
2005-2012 Focus 2.0L VIN N Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2003-2007 Focus 2.3L VIN Z Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2004-2007 Freestar 3.9L VIN 6 Cam Sensor Synch Tool 6470 (511537) 303-630
2004-2007 Freestar 4.2L Cam Sensor Synch Tool 6469 (511536) T96T-12200-A 303-562
2013-2014 Fusion 2.0L Cam Alignment Tool
Crankshaft TDC Timing Pin
6474 (511541)
6475 (511542)
T94P-6256-CH
T97P-6000-A
303-465
303-574
2006-2009 Fusion 2.3L VIN Z Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2010-2014 Fusion 2.5L VIN A Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2010-2014 Fusion Hybrid 2.5L VIN 3 Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
1991-2008 Grand Marquis 4.6L 2V Cam Positioning Tool 6009 (511532) T91P-6256-A 303-380
1992-2008 Grand Marquis 4.6L 2V Cam Positioning Tool 6020 (511555) T92P-6256-A 303-413
1997-2002 Grand Marquis 4.6L VIN W Cam Positioning Tool
Cam Positioning Tool
6009 (511532)
6020 (511555)
T91P-6256-A
T92P-6256-A
303-380
303-413
2005-2008 Mariner 2.3L VIN Z Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2009-2012 Mariner 2.5L VIN 7 Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2005-2008 Mariner Hybrid 2.3L VIN H Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2009-2012 Mariner Hybrid 2.5L VIN 3 Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2006-2009 Milan 2.3L VIN Z Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
2010-2011 Milan 2.5L Cam Alignment Tool 6474 (511541) T94P-6256-CH 303-465
