RunTime=1 Log=2
Part=3 Single=4
Click 4 to access the single open/close menu as shown below:
Open=1 Close=2
Stop=3
At this point, press 1 to open the door one time, press 2 to close the door one time, and press 3 halfway to
stop the door operator.
After the debugging of door operator, single open/close action may be performed to verify that the
operating curve is smooth.
Press SET button to return to the previous menu as shown below:
RunTime=1 Log=2
Part=3 Single=4
Press the Go on/go back key to see the display as follows:
Cycle=5
Press 5 to enter the recycling open/close menu as follows:
St_1/2=1 St_1S=2
St_3S = 3 Stop = 4
St_1/2 means that the open/close interval is 0.5S, St_1S means the interval is 1S, and St_3S means the
interval is 3S.
Cycle operation is mainly used in the door test rig demo operation.
2.5 Open/close Curve
The open/close curve is shown as follows
