OTIS DO3000 - Page 17

User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 17/48
3
Current reference
CurRef
4
Current feedback
CurNow
5
Motor torque
Torque
Percentage display
6
Rotor angle
RotAng
i.e. electrical angle
M315 (Learning result):
1
Learning Result
Door Width
Door width data
M316 (open/close count):
1
Open/close count
ALLCnt
Click the Go On button to clear the
data
2
Current open/close
count
CurCnt
Click the Go On button to clear the
data
M317 (open/close time):
1
Close time
CloTime
2
Open time
OpTime
M321 (run time):
1
Total run time
Total Run Time
Total power-on time
M322 (log)
1
Trouble record
Trouble Record
Recent 16 troubles
2
Trouble number
Trouble Number
Number of troubles
3
Clear trouble record
Clear Record
Clear trouble record
4
Clear trouble
number
Clear Number
Clear trouble record
M323 (part)
1
Software version
SoftWV
1
M324 (Single)
1
Single open
Open
2
Single close
Close
3
Stop
Stop
M325 (Cycle)
1
Open and close
door interval 0.5S
St_1/2
2
Open and close
door interval 1.0S
St_1S
3
Open and close
door interval 3.0S
St_3S
4
Stop
Stop
2.7.2 Parameter List
Controller parameters are as follows:
Function
No.
Name
SVT Display
Setting Range
Ex-factory
Value
Concealed
Class
Attribute
M331（Profile Parameters）:
1
Open
acceleration
Op_Accel
200~1500
1200
0
Normally
2
Open
deceleration
Op_Decel
200~1500
800
0
Normally
