User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 18/48
Function
No.
Name
SVT Display
Setting Range
Ex-factory
Value
Concealed
Class
Attribute
3
Open start
buffer
distance
Op_StartDis
1~100
12
0
Normally
4
Open start
buffer speed
Op_StartSpd
5~100
25
0
Normally
5
Open arrive
buffer
distance
Op_CreepDis
1~100
15
0
Normally
6
Open arrive
buffer speed
Op_CreepSpd
5~50
20
0
Normally
7
Max. open
speed
Op_Speed
100~700
600
0
Normally
8
Close
acceleration
Cl_Accel
200~1500
1200
0
Normally
9
Close
deceleration
Cl_Decel
200~1500
1200
0
Normally
10
Close start
buffer
distance
Cl_StartDis
1~100
1
0
Normally
11
Close start
buffer speed
Cl_StartSpd
5~100
60
0
Normally
12
Close arrive
buffer
distance
Cl_CreepDis
1~100
12
0
Normally
13
Close arrive
buffer speed
Cl_CreepSpd
5~50
20
0
Normally
14
Max. close
speed
Cl_Speed
100~700
600
0
Normally
15
Reopen
deceleration
Reop_Decel
200~10000
3500
1
Normally
16
Open jerk
acceleration
Op_JerkAcc
400~3000
1600
1
Normally
17
Open jerk
deceleration
Op_JerkDec
400~3000
1200
1
Normally
18
Close jerk
acceleration
Cl_JerkAcc
400~3000
800
1
Normally
19
Close jerk
deceleration
Cl_JerkDec
400~3000
500
1
Normally
20
Reopen jerk
deceleration
Reop_Jerk
400~3000
3000
1
Normally
21
Mandatory
close speed
NDG_Speed
20~80
40
1
Normally
22
Door coupler
type
DoorCouplerType
0=
Asynchronou-s
1=
Synchronous
1
1
Outage
23
Door coupler
distance
DoorCouplerDis
1~300
53
1
Normally
24
Door coupler
speed
SCouplerSpd
20~700
100
1
Normally
