OTIS DO3000 - Page 19

User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 19/48
Function
No.
Name
SVT Display
Setting Range
Ex-factory
Value
Concealed
Class
Attribute
M332 (System parameters):
1
Run mode
RunMode
1=Standard
protocol
2=Extend 3
wire protocol
2
0
Normally
2
Door width
data
DoorWidth
learning
acquisition
110
0
Normally
3
open/close
arrive gap
ArriveGap
1~80
10
0
Normally
4
Open arrive
torque
OpArriveTroque
0~300
180
0
Normally
5
Close arrive
torque
ClArriveTroque
0~300
80
0
Normally
6
REV high/low
level setting
REVLevelType
0~1
0
0
Normally
7
DOB high/low
level setting
DOBLevelType
0~1
1
0
Normally
8
open/close
direction
selection
OpenDirection
0~1
0
1
Outage
9
PP inactive
distance
InactivePP
1~100
10
1
Normally
M333(motor parameters):
1
Rated current
Rated I
10~1000
120
0
Outage
2
Number of
motor poles
Num_MotorPole
1~20
8
0
Outage
3
Number of
encoder
pulses
Num_EncoderPulse
360~10000
4096
0
Outage
4
Initial angle of
encoder
IniAngle_Encoder
learning
acquisition
0
0
Outage
5
Distance of
gear for
synchronizing
wheel
Dis_Gear
2~20
5
0
Outage
6
Number of
gears for
synchronizing
wheel
Num_Gear
2~50
26
0
Outage
7
Power-on
initial speed
InitSpd
20~80
60
0
Normally
8
Max. learning
torque
LearnTorq
40~300
130
0
Normally
9
Learning
open arrive
toque
LearnArriveTrq
0~300
120
0
Normally
10
Open hold
torque
Op_HoldTorq
10~100
60
1
Normally
11
Close hold
torque
Cl_HoldTorq
10~100
80
1
Normally
