User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 20/48
Function
No.
Name
SVT Display
Setting Range
Ex-factory
Value
Concealed
Class
Attribute
12
Hold torque
time
HoldTorqTime
0~24
0
1
Normally
13
Hold speed
HoldSpeed
20~80
40
1
Normally
14
Reopen
torque
Reop_JudgeTorq
50~200
100
1
Normally
15
Reopen
acceleration
compensation
Reop_TorqAccSlp
0~100
70
1
Normally
16
Reopen
deceleration
compensation
Reop_TorqDecSlp
0~100
10
1
Normally
17
Reopen
torque limit
Reop_LimitTorq
50~700
200
1
Normally
18
Max. open
torque
Op_MaxTorq
10~700
200
1
Normally
19
Low-speed
open torque
Op_LowSpdTorq
10~700
200
1
Normally
20
Close max
torque
Cl_MaxTorq
10~700
200
1
Normally
21
Close low
speed torque
Cl_LowSpdTorq
10~700
200
1
Normally
22
Allowable
error of initial
angle
Angle EE
10~100
50
2
Normally
23
Initial angle
learning
torque
AngleDutyRatio
200~700
400
2
Normally
24
High speed
ring gain
SpdP1 Gain
0~4000
1800
2
Normally
25
High speed
ring integral
time
SpdI1 Gain
0~4000
50
2
Normally
26
Low speed
ring gain
SpdP2 Gain
0~4000
960
2
Normally
27
Low speed
ring integral
time
SpdI2 Gain
0~4000
30
2
Normally
28
PI switching
speed point
PI ChangSp
0~700
5
2
Normally
29
PI switching
slope
PI ChangeSlp
1~20
1
2
Normally
30
Current loop
gain
CurrentP Gain
100~5120
400
2
Normally
31
Current loop
integral time
CurrentI Gain
0~1000
67
2
Normally
32
Speed
feedback filter
Speed Filter
0~200
100
2
Normally
33
Current
reference
filter
Current Filter
0~2000
0
2
Normally
