User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 21/48
Function
No.
Name
SVT Display
Setting Range
Ex-factory
Value
Concealed
Class
Attribute
34
Reopen judge
time
Reop_JudgeT
10~1000
50
2
Normally
35
Open fault
judge time
Op_JudgeT
10~10000
4000
2
Normally
M336（Debug parameters）：
1
Cycle
operation
allowed bits
EN_Cycle
0~1
1
1
Normally
2
Emergency
opening
mode
EmgOpenMode
0~1
1
1
Outage
3
Service tool
enable bits
EN_SVT
0~1
0
2
Normally
4
Learning
completion
flag
LearnJudge
0~1
0
2
5
Hold torque
enable
En_HoldTorq
0~1
1
2
Normally
6
Overload
threshold
OL_Threshold
1~200
80
2
Normally
7
Phase loss
threshold
PHL Threshold
10~200
100
2
Normally
8
Software
overcurrent
threshold
OC2 Threshold
0~700
400
2
Normally
9
Failure lock
number
Num_Failure Lock
1~30
5
2
Normally
10
Failure
recover time
T_FailureRec
1~60
5
2
Normally
11
Parameter
change
enable bits
EN_ParaChange
0~1
0
2
Normally
12
Power-on
initialization
time
Init_Time
1000~10000ms
3500
2
Power-on
13
Power-on
DOL output
time
DOL_Time
0~2000ms
500
2
Power-on
3. Electrical Debugging (2)
Part number: HAA24360G1~G11
3.1 Wiring of controller
3.1.1 Wiring of HAA24360G1, HAA24360G7 controller components (as shown in Fig.3-1)
