Installing the seating system before assembling the frame and
canvas will make installation easier.
1. Install the seat slide brackets onto the seat swivel using the flathead machine
screws and nylock nuts and washers. Leave the bolts loose enough to
allow them to
be adjusted.
Ratchet & 7/16” socket
7/16” wrench
Short extension for Ratchet or 7//16” deep socket
Drill/Driver
Phillips Bit
Phillips Screwdriver
½” Wrench
½” socket
5/16” Drill Bit
7/16” Drill Bit
Flathead Phillips bolts are inserted
here
Phillips screwdriver is inserted through
these holes to tighten flathead screws.
Washer and nylock nut
attach on the backside.
