Otter Pro XT Lodge - Secure Swivel to Plastic Base; Attach Swivel to Seat

2. Slide brackets and swivel part way onto the plastic base. Adjust the fit to be snug by
pressing in on the brackets. However the brackets still need to be able to slide smoothly
back and forth on the plastic base. Tighten the bolts securely once the fit is correct.
3. Line up the swivel with the inserts in the bottom of the seat. Loosely install the ¼ x ¾”
Phillips head bolt with washers (included in the seat box) into the inserts in the bottom of
the seat. Tighten all 4 bolts securely once the swivel is properly positioned.
Press in on slide
brackets and adjust
for proper fit on
plastic base.
Tighten all 4 nylock
nuts securely once
properly adjusted.
Install Phillips
head bolts and
washers here.
