4. Drill out the four pre-marked holes for the seat rail brackets as shown using a 5/16”
drill bit. The sled may be tipped upside down to make drilling the holes easier.
5. Attach the metal brackets to the seat rail using the 5/16” bolts and nuts. The bracket
with
the greater angle goes toward the front of the sled. Attach plastic end caps onto the
seat
rail using the self tapping screws. A small pilot hole may be drilled to ease
installation.
Drill four pre-marked holes at these
locations.
Drill these 2 pre-marked holes with
a 5/16 drill bit.
Drill these 2 pre-marked holes with
a 5/16 drill bit.
Bracket for front of sled.
Bracket for rear of sled.
