6. After the brackets and end caps are installed the seat rail may be bolted into place
with the ¼” bolts, washers and nylock nuts
using the previously drilled holes.
Install plastic base and seat onto the rail. Use WD-40 or silicone to lubricate plastic
seat base opening so it will go onto the aluminum rail easier.
Install plastic end caps here.
Secure with ¾” self tapping screws.
Install seat rail here. Some
downward pressure may be
necessary to get the holes to
bracket to sled
Bolt front bracket to sled
here.
Lubricate here for easier
pivoting on the seat rail.
Two seat bases and
one seat installed.
