15) Cut the orthosis free and deburr the edges. Ensure that the cut edge at
the foot stirrup runs directly below the ankle joint. This results in the
highest possible supporting surface of the foot stirrup.
16) Transfer the bore holes of the bar and the foot stirrup to the orthosis
shell (see fig.14).
17) Screw the orthotic joints to the orthosis shell.
18) Secure screw connections with Loctite241 (see fig.15).
17AD1*
The 17AD1* orthotic ankle joints are adapted to the needs of the patient
through the individual combination of the ball, stop pin and compression
spring with the set screws.
The following combinations are possible:
Combination
Installation
position
Anterior
Installation
position
Posterior
Intended use
Stop pin Stop pin e.g.ICP or spina bifida
Compression
spring
Stop pin Support for dorsal extension, e.g.in case of
lower leg muscle weakness, to prevent hyper
extension of the knee joint or for energy return
during toe-off
Compression
spring
Compression
spring
Dorsal and plantar support, e.g.in case of
lower leg muscle weakness
Stop pin Compression
spring
Dorsiflexion assist with adjustable dorsal stop,
e.g.in case of peroneal paralysis with or
without own muscular knee joint protection
► Assemble the threaded holes with ball, stop pin and/or compression
spring in the required combination and close the hole with the set screw.
► For final assembly, secure the set screws with Loctite241.
6 Cleaning
Promptly clean the product after contact with water containing salt, chlorine
or soap, or if it gets dirty.
1) Rinse the product with clear fresh water.
2) Dry the product with a cloth or allow it to air dry. Avoid exposure to direct
heat (e.g. from an oven or radiator).
17
