NOTICE
Exposure of the product to unsuitable environmental conditions
Damage, brittleness or destruction due to improper handling
► Avoid storage in condensing ambient humidity.
► Avoid contact with abrasive substances (e.g.sand, dust).
► Do not expose the product to temperatures below -10°C (14°F) or
above +60°C (140°F) (e.g.sauna, excessive sunlight, drying on a
radiator).
5 Preparing the product for use
CAUTION
Repeated bending at the same position
Risk of injury due to breakage of the bar, change in or loss of functionality
► Avoid repeated bending at the same position.
CAUTION
Mechanical damage to the product
Risk of injury due to breakage of the bars, change in or loss of functionality
► Do not carry out any heat treatment on steel or titanium bars at temper
atures above 300°C.
► Do not carry out any heat treatment on aluminium bars at temperatures
above 150°C.
NOTICE
Heat treatment for shaping
Risk of injury due to breakage of the bar, change in or loss of functionality
► Avoid heat treatment for shaping.
Shortening side bars
> Required tools: 702B9 hole gauge, 726S9=90x11.5 countersink, meas
uring tape, pen
1) Check the alignment of the side bars on the model.
2) Optional: Shorten the side bars and adapt the edges to the insertion
zone of the orthotic joint.
3) Use the 702B9 hole gauge for the bores in the insertion zone of the side
bar.
4) Countersink and deburr the bores for the oval countersunk screws with
the countersink.
