Otto Bock 4R21 - Page 8

Nähere Informationen zu den Garantiebedingungen erteilt die zustän
dige Vertriebsgesellschaft des Herstellers.
10 Technische Daten
Rohrdurchmesser: 30mm
Kennzeichen 4R21 4R21=1 4R69 4R69=AL
Gewicht [g]
130 125 75 75
Systemhöhe
[mm]
33
Material
Edelstahl, rostfrei Aluminium
Max. Körperge
wicht [kg]
100 136 125 136
Kennzeichen 4R52 4R52=1 4R56 4R56=1 4R56=2
Gewicht [g]
75 80 85 85 100
Systemhöhe [mm]
33 34 35
Material
Titan
Abwinkelung °
– – 10 20 30
Max. Körperge
wicht [kg]
100 136 100
Rohrdurchmesser: 34mm
Kennzeichen 4R82 4R82=P 4R91
Gewicht [g]
95 90 140
Systemhöhe [mm]
33 -12 33
Material
Titan Edelstahl, rostfrei
Max. Körpergewicht [kg]
150
Kennzeichen 4R156 4R156=1 4R156=2 4WR95=3
Gewicht [g]
145 175 185 130
Systemhöhe [mm]
36 37 38 33
Material
Titan
8
Kennzeichen 4R156 4R156=1 4R156=2 4WR95=3
Abwinkelung [°]
10 20 30 –
Max. Körperge
wicht [kg]
150
1 Product description
English
INFORMATION
Date of last update: 2020-06-04
►
Please read this document carefully before using the product
and observe the safety notices.
►
Instruct the user in the safe use of the product.
►
Please contact the manufacturer if you have questions about the
product or in case of problems.
►
Report each serious incident in connection with the product, in
particular a worsening of the state of health, to the manufacturer
and to the relevant authority in your country.
►
Please keep this document for your records.
1.1 Construction and Function
Tube clamp adapters are used as components for modular lower limb
prostheses. Together with the tube adapter they connect the prosthet
ic foot to the proximal components. Adapter combinations allow for
controlled angle and length adaptation in the sagittal and frontal plane
as well as adjustment of inward and outward rotation. These instruc
tions for use apply to the following tube clamp adapters:
Diameter Reference number
30mm 4R21, 4R21=1, 4R52, 4R52=1, 4R56, 4R56=1,
4R56=2, 4R69, 4R69=AL
34mm 4R82, 4R82=P, 4R91, 4R156, 4R156=1,
4R156=2, 4WR95=3
