Active / passive z50 wheel adjustment
The passive or active mounting positions can be set through adapter plates of the z50. For evaluation as to
whether the z50 can be adapted to the active or passive position, please refer the Technical Data section.
To retrofit the wheelchair, loosen the four screws which are used for adapter plate attachment to the frame
and mount them to the other side of the frame in the new position. In case of the passive position, the
adapter plate is attached to the frame with only three screws.
Active position Passive position
