5.7 Frame / Adapter Plates
The adapter plate for the z50 power add-on drive is
attached to the frame with four screws.
You require the Allen wrench size 4 to loosen and
tighten these screws.
5.8 Assembly of the z50 to Manual Wheelchairs
The individual working steps for the assembly of the z50 to manual wheelchairs are shown on the CD: z50,
art. no. 646DV12, 'More Power for Everyday Life'.
Steel bolt
Clamp
