7
The central plug is attached to the crossbrace where
both braces run closely along each other.
First attach the two plastic clips to the crossbrace.
Screw the metal sheet for central plug attachment
onto these clips. For this purpose you require the
Allen wrench size 3.
Make sure when laying the cables leading to the
central plug that the cables are not clamped while
folding the wheelchair. Always secure cables to
braces with cable ties at random intervals.
Central Plug
