MATE has found the HUB
Port Assignment screen follows the “HUB
Found” screen, each Port showing the
product connected to it
While navigating the various screens
and menus in the MATE, the information
displayed often only applies to a single
device on a single Port. In these cases,
the Port number is displayed in the upper
right hand corner of the MATE screen.
To navigate through the Ports, use the
<PORT> soft key.
Silent P01
inv 0.0 kw zer 0.0 kw
chg 0.0kw buy 0.0 kw
DOWN STATUS PORT
SETUP/MATE/PAGE2-----------------
choose category:
PG1 SUMRY COMM PG3
SETUP/MATE/ COMM-------------
choose category:
BACK REPOLL PC DEBUG
Adding a Device to an Operating HUB
Any time an OutBack device is removed or added to a HUB or its Port is changed, the MATE must re-
poll the system to nd the locations of all the new or moved devices. This is accomplished by
unplugging and re-plugging the MATE from the HUB, or by the following procedure.
NOTE: Turn o all AC output breakers before connecting and programming new devices added to the
HUB.
MAIN------------------------------------
12:00:00P
SUM STATUS SETUP ADV
SETUP ---------------------------
choose device:
FX MATE
SETUP/MATE/PAGE1-----------------
mate code rev: 4.0.5
choose category:
CLOCK CNT GLOW PG2
From the MAIN screen, press
the <SETUP> soft key
Press the <MATE> soft key
Press the <PG2> soft key
Press the <COMM> soft key
Press the <REPOLL> soft
key
Searching
for Devices
HUB FOUND
Port Assignment
1> FX 2> MX 3> 4>
5> 6> 7> 8>
9> 10> 2M>
After repolling, the MATE will
display a Searching for Devices
screen followed by the Port
Assignment screen before
returning to the choose category
screen. MATEs with software
revision 4.0.0 or higher repoll
automatically every 30 seconds.
