S3 User Guide 71 PN 875-0196-000 Rev C1
Appendix C: S3 Screen Description Reference
Display Screen
Table C-2: Display screen button and field descriptions
Button/Field Description
Night Mode buttons
Set the display for viewing in daytime or nighttime lighting.
Control Layout buttons
Set the control buttons on either the left or the right side of the
screen for your preferred access.
Units buttons
Set the unit of measurement (US or Metric) in which the system
displays and records all measurements.
Clock buttons
Set the clock to either a 12-hour or 24-hour format.
Brightness buttons
Adjust the display brightness—range is 1 (dim) to 10 (bright).
