To clean your antenna, wash it with warm, soapy water and wipe dry with a soft cloth. Apply a thin coating of
non-abrasive, car wax. Buff the antenna to a shine. Do not use cleaners with an acetone base as this will strip
the shiny coating.
Specifications
Model: PERTHplus (Cut to American frequencies Not for resale outside North America)
Band Coverage: 80m-75m-40m-30m-20m-17m-15m-12m-1 Om-6m-2m
Feed Impedance: 48-52 Ohms
Power : 100 watts (pep)
Construction: Brass-Stainless Steel-Urethane, 1/4 wave helical.
Mounting: 3/8" x 24tpi (UNF) Male thread (Stainless Steel)
Wander Lead Length: 31" Plug tip to Plug tip.
Supplied with PERTHplus antenna
Qty Part#___________Description
1 Main shaft (Black)
1 x OBWL Wander lead (WL stands for wander lead, 31" in length)
1 x OBSP90 34" long tapered tuning spike with black bead, (installed in antenna, at manufacture)
1 x OBSP30 14" medium length tuning spike with green bead,
Ix OBSP15 6" short tuning spike with red bead.
1 x OBFL Fly lead, black with green plug at one end.
Please quote Part# when ordering replacements.
Optional
OB360C Trunk mount with spring and cable. (Rotates 360 deg)
OB360s 21/2" x 7/8" x 3/16" Steel spring.
OSB Heavy Duty fixed mount.
OBADP 3 /8" unf to 1/2" bsw Stainless steel adapter.
OBQD 3/8" TO 3/8" Quick disconnect adapter (brass & stain less)
OBMT M-Type to 3/8" adapter, (brass)
OBKNK Knockdown Knuckle 3/8" to 3/8" unf
Should you discover your OUTBACKER antenna has been damaged in transit, please notify your supplier, or write to the
manufacturer within seven days. Claims made more than 7 days after delivery will not be recognized.
We hope you will receive much enjoyment from using your OUTBACKER Joey antenna. For technical assistance
in North America contact,
OUTBACKER NORTH AMERICA, INC
214 Second Street
MANCHESTER KY 40962
Phone (606)598-2029
Fax (606)598-4413
OUTBACKER! the renowned HF Amateur Mobile Antenna - bridging the gap in worldwide communications.
