SWR should vary from 1:1 to 1:8. Pay special attention to grounding and antenna placement.
CARE AND MAINTENANCE
All OUTBACKER antenna are fitted with a rubber "O" ring inside the tip to prevent water entering the mainshaft, however
condensation will accumulate on the inside of the shaft, do not be alarmed. This condensation will not harm the antenna, nor will it
cause inferior performance. Just remove the KNURLED LOCKING NUT and shake out any water. Check your antenna after heavy
rain.
To clean your antenna, wash it with warm, soapy water and wipe dry with a soft cloth. Apply a thin coating of non-abrasive car wax.
Buff the antenna to a shine. Do not use cleaners with an acetone base, as this will strip the shiny coating.
Specifications
Model: STEALTHplus (Cut to American frequencies Not for resale outside North America)
Band Coverage: 80m-75m-40m-30m-20m-17m-15m-12m-10m-6m-2m
Feed Impedance: 48-52 Ohms
Power: 100 watts (pep)
Construction: Brass - Stainless Steel - Urethane, 1/4 wave helical.
Mounting: 3/8" x 24tpi (UNF) Male thread (Stainless Steel)
W/Lead Length: 36" Plug tip, to Plug tip.
Supplied with STEALTHplus antenna
Qty__________Part________Description
1 Main shaft. (Black)
1 x OBWL Wander lead. (WL stands for Wander Lead, 36" in length)
Ix OBSP15 5" short tuning spike
Please quote Part when ordering replacements.
Optional
OB360C Trunk mount with spring and cable. (Rotates 360 deg)
OB360s 2 1/2" x 7/8" x 3/16" Steel spring
OSB Heavy Duty fixed mount.
OBADP 3/8" unf to 1/2" bsw Stainless steel adapter.
OBQD 3/8" TO 3/8" Quick disconnect adapter (brass & stainless)
OBMT M-Type to 3/8" adapter, (brass)
OBKNK Knocknown Knuckle 3/8" to 3/8" unf
We hope you will receive much enjoyment from using your OUTBACKER Joey antenna. For technical assistance in
North America contact,
OUTBACKER NORTH AMERICA, INC
214 Second Street
MANCHESTER KY 40962
Phone (606)598-2029
Fax (606)598-4413
OUTBACKER! the renowned HF Amateur Mobile Antenna - bridging the gap in worldwide communications.
