overstock 9005 - Page 2

M4 x 32mm
Wood Screw
x 12
M6 x 25mm
Wood Dowel
x 4
9005 Display Cabinet
Assembly Instructions
Page 2 of 9
Parts List
1
Hardware List
2
1
M6 x
15mm JCB
x 20
9
'L' Bracket
(5005-3)
x 10
Parts in Box B:
16
Allen Key
x 1
7
Q
Drawer Side
(Left Hand) x 1
R
Drawer Side
(Right Hand) x 1
5
M4 x 25mm
Wood Screw
x 10
2
M6 x
60mm JCB
x 8
CSK Cap
Wood Screw
(M6 x 50mm) x 4
WI-0222
N
Drawer Face x 1
O
Drawer Back x 1
P
Drawer Rail x 1
12
Flat
Washer x 8
13
M4 x 20mm
Bolt x 2
15
Handle
(1005) x 4
3
M4 x 16mm
Wood Screw
x 28
11
Spring
Washer x 8
6
4
M4 x 20mm
Wood Screw
x 6
8
10
Shelf Support
(S060)
x 4
14
M4 x 25mm
Bolt x 2
L
Back Panel x 2
M
Drawer Bottom Panel x 1
17
Hinge
x 4
