8. Align the inner chassis with the guide rails as shown, then
slide the inner chassis back into the outer enclosure. Note:
be sure to slide the inner chassis into the same side you
removed it from in Step 3, otherwise the back plate will not
sit ush with the enclosure.
9. Seat the back plate as shown and use a Phillips driver to
re-ax the two screws that you removed in Step 1.
This completes the assembly process.
