43
1. Use Phillips screwdriver to loosen screw in
battery door. When screw head becomes
visible, use to remove door. (Do not pull
screw completely out.)
2. Remove batteries. (SEE IMAGE 1)
3. Locate switches inside battery compartment
(IMAGE 2). Use screwdriver to move switch
to change setting between °F and °C or to
change resolution, adding or removing the
decimal point (e.g. from 1.0° to 1°)
4. Replace batteries and battery door.
Tighten screw.
TO CHANGE PREFERENCES
-58 to +572°F (-50~300°C)
Measurment
Range
Operating
Range
Accuracy
(Tamb=25°C)
Water
Resistance
Rating
32 to +122°F (0~50°C)
-30~150°C: ±0.5°C/0.9°F, otherwise
±1°C/1.8°F or 1% of reading, whichever
is greater
IP66 water resistance
SPECIFICATIONS
1
2
