Terra Installation Manual
2.0 INSTALLATION
2.1 Unwrapping the Product
When removing the shrink wrap,
be cautious with knives and sharp tools
to prevent scratching the paint. The HMI,
temperature + humidity sensor, external
duct pressure sensor and all other
optional field components will be found
in the electrical box or fan compartment.
They are secured there for transport
and to easily find them on the job site.
Pallets are two-way entry; therefore, fork
extenders or 8-foot forks must be used
when moving a palletized unit.
Units are palletized and protected by
a skeletal crate of heat-treated wood.
These crates are constructed using nails;
therefore, to unpack the unit, carefully use
a crowbar or reciprocating saw to detach
each panel. Additional bracing used to
prevent the unit from sliding on the
pallet must also be removed.
Once external packaging is removed,
carefully remove the stretch wrap and
cardboard covering the unit. It is better to
use scissors rather than a knife to avoid
scratching the unit.
External Pipes are protected by wood boxes
that are secured with Poly Strapping and
must also be removed. If a unit has a baserail,
it will be screwed down directly to the pallet.
External Pipes Protected by Wood Boxes
Packaged Unit
