33
Cleaning, Care and Maintenance Chapter 6
English
4. Install a replacement fuse, OxyGo FIT
®
RP#125 (BUSS MDA-12) and reassemble the tip.
Ensure the retainer ring is properly seated and tightened.
OxyGo FIT® Column Change Procedure
NOTE Column change instructions are only to be used when maintenance is
required and are not intended for practice purpose.
1. Turn off the OxyGo FIT® concentrator by pressing the power button to shut down the
device.
2. Remove the OxyGo FIT® concentrator from the carry case, if applicable..
3. Remove the battery from the OxyGo FIT® concentrator.
4. Place the OxyGo FIT® concentrator on its side so that
the underside is visible. The metal column assembly
can be seen on one side of the device.
Fuse
Cigarette Adapter Plug
Retainer Tip
Retainer
CAUTION For continued protection against risk of fire, only use fuse specified.
96-07062-00-01B OxyGo FIT Multilingual Manual.indb 33 11/16/2016 1:09:41 PM
