34
OxyGo FIT® Column Change Procedure (continued)
5. Unlock the column assembly by pushing the latch
button away from the columns.
6. While holding the button open, slide the column
assembly out of the device by pulling on the column
pull handle.
7. Remove the columns completely from the OxyGo
FIT®. Both columns are removed as one piece.
Column (metal tube) Installation
8. Remove dust caps of new column assembly. Make
sure there is no dust or debris where the dust caps
were located.
Open and unlocked
96-07062-00-01B OxyGo FIT Multilingual Manual.indb 34 11/16/2016 1:09:55 PM
