ELECTRICAL PARTS & ACCESSORIES:
AC Power Cord: 1.8m with SAA 2 Pin AU Plug
DC Output Lead: 1.2m with quick connect
Charging Leads: Quick connect 60cm Crocodile Clip Harness
Quick connect 60cm Ring Terminal Harness
Accessory: State of charge indicator
TECHNICAL SPECIFICATIONS:
Model Number OC-PRO600 OC-PRO1200
Output 6A @ 12V 12A @ 12V
Input Voltage 100-240Vac / 1.4A/0.75A(95W) 220-240Vac / 1.8A(175W)
Input Frequency 50/60Hz 50/60Hz
Charge Voltage Gel - 14.1V
AGM&WET - 14.4V
Calcium - 14.7V
Gel - 14.1V
AGM&WET - 14.4V
Calcium - 14.7V
Equalising Voltage Gel - 14.3V
AGM&WET - 14.6V
Calcium - 15.5V
Gel - 14.3V
AGM&WET - 14.6V
Calcium - 15.5V
Float Voltage 13.6V 13.6V
Start Voltage 3V 3V
Operating Temperature -15 to 50° C -15 to 50° C
Storage Temperature -25 to 85°C -25 to 85°C
Operating Humidity 90% RH Max. 90% RH Max.
Size (L*W*H) 182mm x 88mm x 48mm 214mm x 103mm x 55mm
Weight 0.75kg 1.1kg
Approvals CE, UL/cUL, AS/NZS, EMC CE, UL/cUL, AS/NZS, EMC
CHARGING INSTRUCTIONS:
STEP 1 - Pre charge check & electrolyte level check
• Check the Battery Electrolyte levels (Not required on sealed & maintenance free batteries).
If necessary, remove the vent caps and add distilled water so the levels are halfway between
the upper and lower ll lines.
• Check the battery voltage, type and Ah capacity to ensure the charger is compatible and to
determine which Battery Type and Charge Rate settings you will use.
• Ensure the battery is in a well ventilated area and the charger should be as far away from the
battery as the cables permit.
