ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 Adjustable Front Handle
2 Belt Tracking Knob
3 Sanding Guard Release
Button
4 Handle Locking Knob
5 ON/OFF Trigger (not shown)
6 Lock-on Switch (not shown)
7 Dust Canister
8 Variable Speed Dial
BELT SANDER
KNOW YOUR PRODUCT
1. DUST CANISTER
SETUP & PREPARATION
Ensure the tool is disconnected from the power supply
before performing any of the following operations.
To Adjust the Front Handle
1. Slide the dust canister
down onto the dust
extraction port.
2. Move the handle into your
desired position.
3. Regularly check the dust canister and empty when it becomes
1
/3 full for optimum dust extraction.
9 Sandingbelt(tted)
ACCESSORIES
1. Loosen the handle
locking knob.
3. Tighten the handle
locking knob to secure
this position.
2. To remove, slide the dust
canister up off the dust
extraction port.
1/3 Full
