ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
1 On/off Switch
2 Drill Bit Template Guide
3 Grinding Stone Adjustment Dial
DRILL BIT SHARPENER
KNOW YOUR PRODUCT
1. ADJUSTING THE GRINDING STONE
3. Turn the drill bit
sharpener on.
1. Lower the grinding
stone as far as possible
by turning the grinding
stone adjustment knob
anticlockwise.
2. Insert the drill bit into
the same sized template
guide hole.
SETUP & PREPARATION
The tool is recommended for use with a residual current
device with a rated residual current of 30mA or less.
4. Raise the grinding
stone by turning
the grinding stone
adjustment knob
clockwise until it can
be heard touching
the drill bit.
NOTE: RAISING THE GRINDING STONE WILL
PRODUCE AN AGGRESSIVE GRIND AND ROUGH
EDGE. LOWERING THE GRINDING STONE WILL
PRODUCE A FINER GROUND EDGE.
