DBS-3100
4. MAINTENANCE
Changing the Grinding Stone
The grinding stone will need to be changed when grooves or
ridges mar the evenness of the grinding surface.
2. Loosen the two screws
on the top of the drill bit
sharpener.
3. Remove the Index head
assembly.
4. Remove the stone
assemby, ensuring the
spring stays in place.
5. Insert a new grinding
wheel assembly onto the
drive shaft. Rotate until it
locates into place.
6. Replace the index head
assembly, fasten by
tightening the two screws.
1. Raise the grinding stone.
