1. On/off switch
2. Reset button/overload protector
3. Direction control switch
4. Cutting adjustment bolt
5. Feeding hopper
6. Discharge chute
7. Transport handle
8. Stand
9. Wheels
SPECIFICATIONS - MODEL NO. SSH-240
2
1
9
3
2
6
Motor:
Input:
No load speed:
Max cutting diameter:
Blades:
Protection class:
Tool weight:
2400W (S1 2000W / S6 (40%) 2400W)
Duty type S1: continuous running duty
S6: continuous-operation / periodic duty
(4 min. Full load, 6 min. No load)
230-240V ~ 50Hz
40/min
40mm
Roller cutting system
I (earthed appliance)
23kg
Assembly components
10. Shredder housing
11. Support legs (x2)
12. Wheel axle
13. Wheels (x2)
14. Wheel caps (x2)
15. Wheel locking insert (x2)
16. Nut & washers (to attach legs) (x4)
17. 55mm screws, nut & washers (to attach axle) (x2)
18. Hex wrench
19. Hex key
20. Collection bag
5
8
10
11
13
14
20
7
4
17
19
18
16
15
12
