Ozone SPYDER 3 - Technical Specifications

TECHNICAL SPECIFICATIONS
32
26 28
22
24
No. of Cells
48 48 48 48 48
48
Projected Area (m2)
17.2 18.9 20.6 22.4 24.1
25.8
Flat Area (m2)
20 22 24 26 28
30
Projected Span (m)
7.93 8.32 8.69 9.04 9.39
9.71
Flat Span (m)
10.1 10.59 11.06 11.52 11.95
12.37
Projected Aspect Ratio
3.7 3.7 3.7 3.7 3.7
3.7
Flat Aspect Ratio
5.1 5.1 5.1 5.1 5.1
5.1
Root Chord (m)
2.54 2.67 2.79 2.9 3.01
3.11
Glider Weight (Kg)
3.91 4.19 4.22 4.66 4.88
5.13
Free ight Weight Range (Kg)
50-70 55-80 65-85 80-100 95-120
110-140
PPG Weight Range (Kg)
55-100 55-105 65-120 80-140 95-160
110-190
Load test @5.25G (kg)
256 256 256 256 256 256
Certication DGAC
DGAC DGAC DGAC DGAC DGAC DGAC
30
Trimmed
Untrimmed
A 500mm
A
2
490mm
B 475mm
C 450mm
D 425mm
A 500mm
A
2
515mm
B 530mm
C 560mm
D 590mm
A 340mm
A
2
367mm
B 393mm
C 447mm
D 500mm
Neutral - Accelerated
Riser Lengths
Neutral
A 500mm
A
2
500mm
B 500mm
C 500mm
D 500mm
Accelerator range - 16cm Trimmer range - 16.5cm
20
