Ozone ZENO 2 - MATERIALS

Leading
Edge
Trailing
Edge
Risers
Cell
Openings
Riser
Lines
Middle
Lines
Upper
Lines
Brake
Lines
Main Hangpoint
to Harness Karabiner
A
Riser
AR3
Riser
B
Riser
Pulley
Brummel Hook
for Speed System
Ball Bearing
Pulleys
Brake
Handle
Upper Surface
Lower Surface
Butt Hole
B Riser
Handle
TECHNICAL DRAWINGS
29
Non Accelerated
Accelerated
Pulleys axis - axis
A 530mm
A
3
522mm
B 515mm
A 370mm
A
3
443mm
B 515mm
350mm
S, MS,
ML & L,
160mm
Accelerator Range (fully overlapped)
