Ozone Zeno - Technical Specifications

TECHNICAL SPECIFICATIONS
28
No. of Cells 78 78 78 78
Projected Area (m2) 17.8 19.0 20.4 22.4
Flat Area (m2) 21.0 22.5 24.1 26.5
Projected Span (m) 9.6 9.9 10.3 10.8
Flat Span (m) 12.0 12.5 12.9 13.5
Projected Aspect Ratio
5.2 5.2 5.2 5.2
Flat Aspect Ratio 6.9 6.9 6.9 6.9
Root Chord (m) 2.19 2.26 2.34 2.45
Weight (Kg) 4.8 5.0 5.3 5.7
Max Control Travel
(cm) 65 65 65 65
I
n-Flight Weight Range 75-90 85-100 95-110 105-125
Certication EN/LTF D D D D
S MS
ML
L
