5.1.3 Heating and/or cooling coil(s) configuration: press ENTER until the item menu « SAT BA? »
appears:
SAT BA? Select YES, in case of presence of Heating and/or cooling coil(s)
TYPE BA?
If YES, select the installed coil configuration:
- if heating coil: BA+,
- if water cooling coil: BA-,
- if heating/cooling coil (reversible coil): BA+/-,
- if heating coil + one cooling coil (separate): BA+/BA-,
- if electrical coil: KW,
- if electrical coil + one cooling coil: BA-/KW.
Wiring diagram: see appendix 8.
5.1.4 Type of comfort regulation configuration: press ENTER until the item menu « COMFORT » appears:
COMFORT
ON Tx?
Select T5 or T2.
Regulation of the comfort T° on supply (T5) or on ambiance (T2). The temperature
measured on the selected sensor serves as a reference for regulating the heating or
cooling power.
For connections, configuration and user instructions: see installation manual MI ROOM T° SENSOR.
Exit the menu by pressing the SETUP button.
5.2 Basic configuration
This is the configuration of the setpoints for the operation of the unit (airflows, temperatures, ...).
Configuration of the fan is made using the LCD display and the 4 setup knobs. SETUP, ↑, ↓ and ENTER.
To start the configuration press SETUP until SETUP text appear on the LCD.
The principle of selection is to use keys ↑and ↓ to make the choice and to press ENTER to confirm. The numbers
are introduced figure by figure.
Below you will find a simplified configuration for the use with only one fan.
Complete information is available on the PLC website : www.lemmens.com
1 LANGUAGE Language choice
2 DISPLAY m³h ? If yes, the airflow of each fan will be displayed on the screen
3 DISPLAY Pa ? If yes, the pressure of each fan will be displayed on the screen
4 DISPLAY m/s? If yes, the air speed of each fan will be displayed on the screen (Fill in surface in m²)
5 TYPE VEN Choice of fan through (CID – see label on fan)
6 # FAN? Select number of fans connected to CB (F1 or F1+F2).
7
HEATING
T°? xx°C
Only available with post-heating exchanger(s). Select the comfort T° to the heating
exchanger which is connected to the SAT BA.
8
COOLING
T°? xx°C
Only available with post-cooling exchanger(s). Select the comfort T° to the cooling
exchanger which is connected to the SAT BA.
9 MODE Choice of working mode (CA, LS, CPf, CPs)
If MODE CA
10 m³h K1? Select Airflow 1 for each F1,F2 fan (contacts between terminals K1 and +12V closed)
11 m³h K2? Select Airflow 2 for each F1,F2 fan (contacts between terminals K2 and +12V closed)
12 m³h K3? Select Airflow 3 for each F1,F2 fan (contacts between terminals K3 and +12V closed)
10 V min? Select minimum voltage value for LS link
11 V max? Select maximum voltage value for LS link
12 m³/h≡Vmin Select airflow for each F1,F2 fan corresponding to Vmin
13 m³/h≡Vmin Select airflow for each F1,F2 fan corresponding to Vmax
14 % on K3? Select multiplier of airflow when terminals +12V and K3 are closed (‘night’ setup).
NEXT if MODE CA or LS
15
CONFIG
TIME? N
Select Y to configure time and date
16 TIME Select Y to activate the time segment scheduling function
To Next Page
