13 MAN 9054233_9054739_9058170 EN V3
P. Lindberg A/S Sdr. Ringvej 1 www.p-lindberg.dk
Tel.: +45 7021 2626 DK-6600 Vejen E-mail: salg@p-lindberg.dk
Before putting the mower into operation
Before putting the mower into operation, always inspect the mechanical
components, focusing particularly on the condition of the cutting unit,
PTO, hydraulic system and protective shields.
Installation:
The mower comes assembled, so the user only has to attach the shields.
It is strictly forbidden to use the mower without shields, with damaged
shields or with raised shields.
The mower is delivered as shown on the right.
• Removed the packed components for the
shields.
• Lower and attach the stabiliser.
• Take the carrying arm out of the clevis bolt
(photo A).
• Carefully lower the frame with linkage frame
down on the stabiliser.
• Use the cotter pin to attach the carrying arm to
the clevis bolt (photo B) and secure it with
cotter pin and locking pin.
