16
3.3 Place the metal washer and curved plastic washer onto the quick release handle (1)
3.4 Line the holes up on the upper and lower handle and insert the quick release lever
through both holes, ensuring the curve of the plastic washer, matches the curve on the
handlebars (2).
3.5 Secure in place using the nut. Do not overtighten the nut and continually check there is
enough free movement for the quick release lever to operate correctly. (3).
