17
3.6 Insert the two central mounting panel tabs into the slots provided on the upper
handlebar (1).
3.7 Place the central ignition panel so it rests on the 2 mounting tabs (2).
3.8 Line up the screw holes on the ignition panel with the screw holes on the two central
mounting panel tabs and secure in place using the screws provided (3).
3.9 Lift the rear discharge flap and remove the mulching plug if installed. (1).
3.10 Using the hooks on the grass bag, hook the grass bag over the bar at the rear of the
lawn mower (2).
3.11 Lower the rear discharge flap until it rests on the grass bag (3).
3.12 Connect the battery and ignition to the engine by tracking the cable from the centre
ignition panel and plugging it into the plug on the main lawn mower engine.
