24
4.8 Gently pull the recoil start handle until you feel resistance (1).
4.9 Then pull the handle swiftly, until the lawn mower starts (2).
4.10 Charge the battery for 5 hours before first use and then after every 10 uses on
average (1).
4.10 Make sure the blade is free of long grass and the cutting height is set to maximum (1).
4.11 Pump the primer bulb 5 times (2).
4.12 Push the choke lever fully forward (1).
4.13 Pull the Operator Presence Control (OPC) lever (2) towards the main handle.
1
COLD ELECTRIC START – P5100SPE ONLY
2
3
1
1
2
2
