29
6.19 Do not put hands or feet near or under any rotating parts.
6.20 Never pick up or carry a lawn mower while the engine is running.
6.21 Before attempting to clear blockages, check, clean, refuel or after striking a foreign
object – Stop the engine, allow to cool and disconnect the spark plug cap.
Make sure the blades have come to a complete stop.
6.22 Lift the rear discharge flap (1).
6.23 Remove the mulching plug if your model has the mulching option.
6.24 Hook the grass catcher over the mounting points (2) and lower the rear discharge flap
down onto the grass collector (3).
6.25 Life the rear discharge flap and remove the grass collector (1).
6.26 Insert the mulching plug into the rear discharge chute until it clicks into place (2).
6.27 Lower the rear discharge flap (3).
