- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
TERAPRESS TP 7500S
Mounting Press
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1-520-882-6598 Fax +1-520-882-6599 email: pace@metallographic.com Web: https://www.metallographic.com
The TERAPRESS TP 7500S mounting press has been designed for mounting non-flammable
metallographic specimens up to 2-inch diameter. Always follow proper operational guidelines
and avoid contact with moving parts and hot assemblies. Seek appropriate medical care for
burn injuries.
1.3 Emergency Statement
2
!
Always completely tighten the bayonet cover. Improper installation can result
in hot molten mounting material leaking (danger of burning).
!
Initial cooling water coming into contact with mold will produce an initial burst
of steam. To avoid danger of burning, secure the drain line and use caution
when the TERAPRESS TP 7500S compression mounting press is in use.
!
Mold cylinder and ram get very hot during the mounting process. Take care
before changing (danger of burning).
!
Mounting samples must be chemically compatible with the mounting material.
Do not mount flammable samples.
!
Before opening the unit, disconnect main power plug. Replacement parts
should be installed only by qualified personnel.
!
Follow proper operating instructions (Section 4.0) and obtain proper training
before operation.
!
Do not leave press unattended during operation.
!
Turn off external water supply when press is not in operation.
1.2 Safety Precautions (continued)
