- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - ▲ INSTRUCTION MANUAL
TERAPRESS TP 7500S
Mounting Press
Please read this instruction manual carefully and follow all installation, operating and safety guidelines.
3601 E. 34th St. Tucson, AZ 85713 USA Tel. +1-520-882-6598 Fax +1-520-882-6599 email: pace@metallographic.com Web: https://www.metallographic.com
2.2 Technical Specifications
4
Electrical specifications: 110 or 220 Volts (set at factory)
Heating specifications: 1000 Watt (110V / 15 amp)
2000 Watt (110V / 20 amp)
2000 Watt (220V / 10 amp)
Thermostat range: Room temperature to 392ºF
(200ºC)
Hydraulic pressure range: Max. 6460 psi
Timer: 0 - 99 minutes
Mold sizes: 1, 1.25, 1.5 and 2-inch
25, 30, and 40-mm
Weight: 102 lbs (46 kg)
Dimensions (WxHxD): 31 x 19 x 19-inches
(534 x 485 x 485 mm)
Working temperature: 32° - 100°F (0 - 40ºC)
Shipping temperature: 32° - 100°F (0 - 40ºC)
Storage temperature: 32° - 100°F (0 - 40ºC)
Water supply connection: 8 mm quick connect
Water drain connection: 1/4” heater hose
Fuse: 10 amp fast blow
EU Directives: Machinery directive 2006/42/EC
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility directive 2004/108/EC
EU Harmonized Standards: EN ISO 1200:2010
EN 61010-1:2010
EN 61326-1:2006
