6. To assemble the Seat, Handrails, and Seat Sliding Base
Step 6A: Attach the Seat (102) to the Seat Base (51)
with Bolts (108), Washers (5) and 6mm Allen Wrench
(118).
A
Self tapping screw
ST4.0x25 4PCS (41)
Allen Bolt
M6 x 35 2PCS (91)
Washer 18x9x2.0t 6PCS(5)
Allen Bolt M8x15 4PCS (108)
Allen Bolt
M8x45 2PCS (114)
M8 Acorn Nut 2PCS (110)
Spring washer M8x2.0t 2PCS (112)
13
